CCS壓力開關611G系列

CCS 壓力開關 611G 611GE 系列611G接口尺寸1/4"接口材料合金隔膜材料聚丁鈉橡膠最大允許壓力(MPa)設定壓力范圍(MPa)壓力開關型號SPDTDPDT1.7240.010～0.078611G8001611GM80013.4480.083～0.193611G8003611GM80033.4480.208～0.462611G8005611GM80053.4480.483

詳細介紹

CCS 壓力開關 611G 611GE 系列

611G

接口尺寸	1/4"
接口材料	合金
隔膜材料	聚丁鈉橡膠

最大允許壓力(MPa)	設定壓力范圍(MPa)	壓力開關型號
最大允許壓力(MPa)	設定壓力范圍(MPa)	SPDT	DPDT
1.724	0.010～0.078	611G8001	611GM8001
3.448	0.083～0.193	611G8003	611GM8003
3.448	0.208～0.462	611G8005	611GM8005
3.448	0.483～1.193	611G8007	611GM8007

611GE

接口尺寸	1/4"
接口材料	合金
隔膜材料	聚丁鈉橡膠

最大允許壓力(MPa)	設定壓力范圍(MPa)	壓力開關 型號
最大允許壓力(MPa)	設定壓力范圍(MPa)	SPDT	DPDT
1.724	0.010～0.078	611GE8001	611GEM8001
3.448	0.083～0.193	611GE8003	611GEM8003
3.448	0.208～0.462	611GE8005	611GEM8005
3.448	0.483～1.193	611GE8007	611GEM8007

接點容量

電壓	電流
	SPDT	DPDT
	Res	Res
125AC-50/60Hz	11	11
250AC-50/60Hz	11	11
30DC	5	5
125DC	5	5

Highly reliable devices utilizing the CCS Dual-Snap? Belleville disc spring principle pioneered by CCS’ engineers.
Engineering based on aerospace technology.
Rigid, compact and externally adjustable for factory setting or convenient field set point adjustment.
Repeatable and stable set points.
Vibration and shock resistant.
High cycle life.
High over-pressure capability.
Various options for wetted materials and electrical ratings to meet a wide range of application requirements and media compatibility.

SERIES:

611G*
611GZ*
611V*

SET POINT RANGE:

GAGE PRESSURE:

.75 to 180 PSIG
.052 to 12.4 bar
5.17 to 1241 kPa

VACUUM:

1.5 to 28.5” Hg
38 to 724 mm Hg
